1. DIP SWITCH 1
Remote controller address 1
Remote controller address1,2.
Used for setting of the remote controller address. Set the addresses by ordering MASTER SLAVE
without any space.
Cooling only / heat pump.
Switching cooling only / heat pump is set with SW2-1.
1
■ WIRED REMOTE CONTROLLER
3
1
REMOTE CONTROLLER ADDRESS 1,2 SWITCH
Method
OFF Master
SW1-3 SW1-4
OFF ON Slave
OFF
COOLING ONLY / HEAT PUMP SWITCH
Operation system
Heat pump
SW2-1
ON Cooling only
OFF
Auto change over validity / invalidity.
Auto change over validity / invalidity is set with SW2-2.
2
FINAL REMOTE CONTROLLER SWITCH
Terminator
NO
SW1-1
ON YES
OFF
Indoor unit connection.
This is switched according to No. of connected indoor unit.
2
No. INDOOR UNIT CONNECTION SWITCH
Number of indoor unit
One unit connection
SW1-2
ON Multiple unit connection
OFF
SW1-5 and SW1-6 setting are forbidden.4
2. DIP SWITCH 2
AUTO CHANGEOVER SWITCHING
Auto restart
Invalidity
SW2-2
ON Validity
OFF
