Page #186 background imageLoading...
Page #186 background image
Ref Ord
No. ABY12TFAMF ABY14TFAMF ABY18TFAMF ABY24TFAMF ABY30TFAMF ABY36TFAMF ABY45TFAMF ABY54TFAMF Q'ty
Description
Parts No.
RESISTOR.CHIP 0200230627 0200230627 0200230627 0200230627 0200230627 0200230627 0200230627 0200230627
RESISTOR.CHIP 0201010013 0201010013 0201010013 0201010013 0201010013 0201010013 0201010013 0201010013
RESISTOR.CHIP 0201010426 0201010426 0201010426 0201010426 0201010426 0201010426 0201010426 0201010426
RESISTOR.CHIP 0201010501 0201010501 0201010501 0201010501 0201010501 0201010501 0201010501 0201010501
RESISTOR.CHIP 0201010648 0201010648 0201010648 0201010648 0201010648 0201010648 0201010648 0201010648
RESISTOR.CHIP 0201010747 0201010747 0201010747 0201010747 0201010747 0201010747 0201010747 0201010747
RESISTOR.CHIP 0201010907 0201010907 0201010907 0201010907 0201010907 0201010907 0201010907 0201010907
RESISTOR.CHIP 0201011010 0201011010 0201011010 0201011010 0201011010 0201011010 0201011010 0201011010
RESISTOR.WIRING 0200244372 0200244372 0200244372 0200244372 0200244372 0200244372 0200244372 0200244372
67 RUBBER 313659068604 313659068604 313659068604 313659068604 313659068604 313659068604 313659068604 313659068604
185-1 RUBBER BUSHING ---------------- ---------------- ---------------- ---------------- 9357376004 9357376004 9357376004 9357376004
427-1 RUBBER SHEET-A ---------------- ---------------- ---------------- ---------------- 9364097008 9364097008 9364097008 9364097008
427-2 RUBBER SHEET-B ---------------- ---------------- ---------------- ---------------- 9364098005 9364098005 9364098005 9364098005
424 SECTOR GEAR ---------------- ---------------- ---------------- ---------------- 9359729006 9359729006 9359729006 9359729006
138 SEPARATE WALL ---------------- ---------------- ---------------- ---------------- 9359700005 9359700005 9359700005 9359700005
138 SEPARATE WALL-A 9358584002 9358584002 9358584002 9358584002 ---------------- ---------------- ---------------- ----------------
138 SEPARATE WALL-B 9358585009 9358585009 9358585009 9358585009 ---------------- ---------------- ---------------- ----------------
286 SHAFT HOLDER BRACKET ---------------- ---------------- ---------------- ---------------- 9359686002 9359686002 9359686002 9359686002
403 SHAFT HOLDER FIXTURE ---------------- ---------------- ---------------- ---------------- 9359687009 9359687009 9359687009 9359687009
122 SHAFT HOLDER-B ---------------- ---------------- ---------------- ---------------- 9357921006 9357921006 9357921006 9357921006
384 SHAFT.( SIROCCO FAN ) ---------------- ---------------- ---------------- ---------------- 9359707004 9359707004 9359707004 9359707004
762 SIDE COVER-L ---------------- ---------------- ---------------- ---------------- 9359741008 9359741008 9359741008 9359741008
761 SIDE COVER-R ---------------- ---------------- ---------------- ---------------- 9359740001 9359740001 9359740001 9359740001
761 SIDE COVER-R ASSY 9359069010 9359069010 9359069010 9359069010 ---------------- ---------------- ---------------- ----------------
599 SIGNAL PCB ASSY 9703728013 9703728013 9703728013 9703728013 9703728013 9703728013 9703728013 9703728013
56 SIROCCO FAN ASSY 9358621004 9358621004 9358621004 9358621004 ---------------- ---------------- ---------------- ----------------
56 SIROCCO FAN ASSY ---------------- ---------------- ---------------- ---------------- 9359701002 9359701002 9359701002 9359701002
SOCKET.PWB 0500296033 0500296033 0500296033 0500296033 0500296033 0500296033 0500296033 0500296033
468 SPECIAL NUT-A ( LARGE ) ---------------- ---------------- ---------------- ---------------- 313005446653 313005446653 313005446653 313005446653
469 SPECIAL NUT-B ( SMALL ) ---------------- ---------------- ---------------- ---------------- 313005446759 313005446759 313005446759 313005446759
365-2 SPECIAL SCREW 9359091004 9359091004 9359091004 9359091004 ---------------- ---------------- ---------------- ----------------
365-1 SPECIAL SCREW 9359092001 9359092001 9359092001 9359092001 ---------------- ---------------- ---------------- ----------------
SPECIAL SCREW ---------------- ---------------- ---------------- ---------------- 9360452009 9360452009 9360452009 9360452009
SPECIAL SCREW ---------------- ---------------- ---------------- ---------------- 9360453006 9360453006 9360453006 9360453006
876-1 STEP MOTOR-H 9359106012 9359106012 9359106012 9359106012 ---------------- ---------------- ---------------- ----------------
876-1 STEP MOTOR-H ---------------- ---------------- ---------------- ---------------- 9360479013 9360479013 9360479013 9360479013
876-2 STEP MOTOR-V 9359105015 9359105015 9359105015 9359105015 ---------------- ---------------- ---------------- ----------------
876-2 STEP MOTOR-V ---------------- ---------------- ---------------- ---------------- 9360307026 9360307026 9360307026 9360307026
909 STRAINER A ---------------- ---------------- ---------------- ---------------- 9365457009 9365457009 9365457009 9365457009
909 STRAINER C ---------------- ---------------- 9365443002 9365443002 ---------------- ---------------- ---------------- ----------------
996 STRAINER G 9365455005 9365455005 9365455005 9365455005 9365455005 9365455005 9365455005 9365455005
502 SUPPORT STAY 9358599006 9358599006 9358599006 9358599006 ---------------- ---------------- ---------------- ----------------
SWITCH.PUSH 9700450016 9700450016 9700450016 9700450016 9700450016 9700450016 9700450016 9700450016
SWITCH.ROTARY 9701694013 9701694013 9701694013 9701694013 9701694013 9701694013 9701694013 9701694013
SWITCH.SLIDE 9701393015 9701393015 9701393015 9701393015 9701393015 9701393015 9701393015 9701393015
TEMPLATE 9359107002 9359107002 9359107002 9359107002 ---------------- ---------------- ---------------- ----------------
TEMPLATE ---------------- ---------------- ---------------- ---------------- 9360022004 9360022004 9360022004 9360022004
815 TERMINAL 7P 9703403040 9703403040 9703403040 9703403040 9703403040 9703403040 9703403040 9703403040
253 TERMISTOR ( PIPE ) 9704054012 9704054012 9704054012 9704054012 ---------------- ---------------- ---------------- ----------------
652-1 THERM.HOLDER PIPE 313806262805 313806262805 313806262805 313806262805 313806262805 313806262805 313806262805 313806262805
234 THERMISTOR ASSY-ROOM 9703299025 9703299025 9703299025 9703299025 9703299025 9703299025 9703299025 9703299025
234-1 THERMISTOR ASSY-ROOM 9704053015 9704053015 9704053015 9704053015 9704053015 9704053015 9704053015 9704053015
163-2/184-1 THERMO.SPRING-A 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708
TOP COVER 9358534014 9358534014 9358534014 9358534014 ---------------- ---------------- ---------------- ----------------
TOP COVER ---------------- ---------------- ---------------- ---------------- 9359737001 9359737001 9359737001 9359737001
TRANSEORMER (SWITCHG) 9702727017 9702727017 9702727017 9702727017 9702727017 9702727017 9702727017 9702727017
TRANSISTOR 0000164047 0000164047 0000164047 0000164047 0000164047 0000164047 0000164047 0000164047
TRANSISTOR 0000699235 0000699235 0000699235 0000699235 0000699235 0000699235 0000699235 0000699235
TRANSISTOR 0000781053 0000781053 0000781053 0000781053 0000781053 0000781053 0000781053 0000781053
TRANSISTOR 0000936033 0000936033 0000936033 0000936033 0000936033 0000936033 0000936033 0000936033
TRANSISTOR 0000936033 0000936033 0000936033 0000936033 0000936033 0000936033 0000936033 0000936033
VARISTOR 0000038010 0000038010 0000038010 0000038010 0000038010 0000038010 0000038010 0000038010
VARISTOR ( ARRESTER ) 0600168032 0600168032 0600168032 0600168032 0600168032 0600168032 0600168032 0600168032
357 WALL HOOK BRACKET 9358597002 9358597002 9358597002 9358597002 ---------------- ---------------- ---------------- ----------------
WIRE ASSY 9703757044 9703757044 9703757044 9703757044 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( COMUMUNICAT ) ---------------- ---------------- ---------------- ---------------- 9703757020 9703757020 9703757020 9703757020
253- WIRE ASSY ( CONNECTER ) 9702068011 9702068011 9702068011 9702068011 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9360534019 9360534019 9360534019 9360534019
253- WIRE ASSY ( CONNECTER ) 9701875016 9701875016 9701875016 9701875016 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( CONNECTER ) 9702068042 9702068042 9702068042 9702068042 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9702264017 9702264017 9702264017 9702264017
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9702311018 9702311018 9702311018 9702311018
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9702317010 9702317010 9702317010 9702317010
253- WIRE ASSY ( CONNECTER ) 9702318024 9702318024 9702318024 9702318024 9702318024 9702318024 9702318024 9702318024
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9702319014 9702319014 9702319014 9702319014
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9702323011 9702323011 9702323011 9702323011
253- WIRE ASSY ( CONNECTER ) ---------------- ---------------- ---------------- ---------------- 9702419011 9702419011 9702419011 9702419011
253- WIRE ASSY ( CONNECTER ) 9703301018 9703301018 9703301018 9703301018 9703301018 9703301018 9703301018 9703301018
253- WIRE ASSY ( CONNECTER ) 9703763014 9703763014 9703763014 9703763014 9703763014 9703763014 9703763014 9703763014
253- WIRE ASSY ( CONNECTER ) 9703875014 9703875014 9703875014 9703875014 9703875014 9703875014 9703875014 9703875014
253- WIRE ASSY ( FAN MOTOR ) 9702068028 9702068028 9702068028 9702068028 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( FAN.CAPA. ) 9701951017 9701951017 9701951017 9701951017 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( P/S PCB ) 9702067014 9702067014 9702067014 9702067014 ---------------- ---------------- ---------------- ----------------
253- WIRE ASSY ( TERMINAL ) ---------------- ---------------- ---------------- ---------------- 9703440014 9703440014 9703440014 9703440014
253- WIRE ASSY ( TERMINAL ) ---------------- ---------------- ---------------- ---------------- 9703441011 9703441011 9703441011 9703441011
253-1 WIRE ASSY ---------------- ---------------- ---------------- ---------------- 9702313036 9702313036 9702313036 9702313036
253 WIRE ASSY 9702313029 9702313029 9702313029 9702313029 ---------------- ---------------- ---------------- ----------------
WIRE WITH CONNECTOR 9703876011 9703876011 9703876011 9703876011 ---------------- ---------------- ---------------- ----------------
WIRE WITH CONNECTOR ---------------- ---------------- ---------------- ---------------- 9703876028 9703876028 9703876028 9703876028
XTAL.RESONETOR 9703542015 9703542015 9703542015 9703542015 9703542015 9703542015 9703542015 9703542015
– 179 –
Models : ABY12TFAMF,ABY14TFAMF,ABY18TFAMF,ABY24TFAMF
ABY30TFAMF,ABY36TFAMF,ABY45TFAMF,ABY54TFAMF
