Installation and operating manual “1350-EN” 9
Heat pump, Split, single service
Figure 2 - Dimensions in mm
31 77900330 12
9
400
650
21
1290
147
170
196
370
99
3/8”
5/8”
Air
Overflow hole (Ø 20) 4 Ø 10)Holes
Top view
Front view
Sight of lower part
Side view
Air
Air
F
Outside unit,
Model 128, 155
480
88
235
450
1034
1000
Front view
Side view
Heating flow
Ø M 26x34
Heating return
Ø M 26x34
Figure 3 - Dimensions in mm
F
Hydraulic module
