2008.10.28 2
Top view
699 (Hanging bolt position)
890 (Ceiling opening measurement
795 (Hanging bolt position)
Bottom view
950 (Panel measurement)
Drain pipe
Drain pipe diameter
Inside : 20 mm
Outside : 26 mm
796
Bottom view
840
669
DIMENSIONS
(Unit : mm)
INDOOR UNIT
DECORATION PANEL
Side view
Liquid pipe
Gas pipe
288
358 338
60
130
170
133
190
