Installation and operating manual “1350-EN” 35
Heat pump, Split, single service
44 I Operation HC2 Jointly with HC1 |
Independent
Jointly with
HC1
This function enables you to choose whether you wish the room thermostat (as an option) to act on both zones or
just a single zone.
46 I Operation HCP Jointly with HC1 |
Independent
Jointly with
HC1
70 S Software version
Heating time programme, circuit 1
500 U Pre-selection (day / week)
Mon-Sun Mon-Fri Sat-Sun Monday Tuesday…
Mon-Sun
501 U 1st phase On (start) 00 : 00… - -:- - 10 min 6:00
502 U 1st phase Off (end) 00 : 00… - -:- - 10 min 22:00
503 U 2nd phase On (start) 00 : 00… - -:- - 10 min - -:- -
504 U 2nd phase Off (end) 00 : 00… - -:- - 10 min - -:- -
505 U 3rd phase On (start) 00 : 00… - -:- - 10 min - -:- -
506 U 3rd phase Off (end) 00 : 00… - -:- - 10 min - -:- -
516 U Standard values, Circuit 1 no, yes no
Yes + OK: The standard values memorised in the regulator replace and cancel the customised heating
programmes. Your customised settings are therefore lost.
Heating time programme, circuit 2
Only with the 2nd circuit kit option
520 U Pre-selection (day / week)
Mon-Sun Mon-Fri Sat-Sun Monday Tuesday…
Mon-Sun
521 U 1st phase On (start) 00 : 00… - -:- - 10 min 6:00
522 U 1st phase Off (end) 00 : 00… - -:- - 10 min 22:00
523 U 2nd phase On (start) 00 : 00… - -:- - 10 min - -:- -
524 U 2nd phase Off (end) 00 : 00… - -:- - 10 min - -:- -
525 U 3rd phase On (start) 00 : 00… - -:- - 10 min - -:- -
526 U 3rd phase Off (end) 00 : 00… - -:- - 10 mn - -:- -
536 U Standard values, Circuit 2 no, yes no
Yes + OK: The standard values memorised in the regulator replace and cancel the customised heating
programmes. Your customised settings are therefore lost.
Time programme 4 / DHW
If the installation is fitted with a DHW tank. (Only with the DWH kit option)
560 U Pre-selection (day / week)
Mon-Sun Mon-Fri Sat-Sun Monday Tuesday…
Mon-Sun
561 U 1st phase On (start) 00 : 00… - -:- - 10 min 00:00
562 U 1st phase Off (end) 00 : 00… - -:- - 10 min 05: 00
563 U 2nd phase On (start) 00 : 00… - -:- - 10 min - -:- -
564 U 2nd phase Off (end) 00 : 00… - -:- - 10 min - -:- -
565 U 3rd phase On (start) 00 : 00… - -:- - 10 min - -:- -
566 U 3rd phase Off (end) 00 : 00… - -:- - 10 min - -:- -
Line
Function Setting range
or display
Setting
increment
Basic
setting
