Fujitsu AOYD36LATT User Manual

5V
D207
EMAA3863X-J300K ORANGE
R202 220
<1/4W>
R203 390
<1/4W>
R204 560
<1/4W>
PHA201
PIC-37143TH5
JM201
VCC
OUT
GND
2
1
3
C201
0.1
<F>
C202
10/
16V
+
SW201
EVQPAG04K
1
3
2
4
1
2
3
4
5
6
7
8
CN201
08 / 08 JC25 / XMR
1430 L=200
BROWN
RED
ORANGE
YELLOW
WHITE
BLUE
PURPLE
GRAY
( OPERATE )
( TIMER )
( LOUVER )
( LOUVER )
( 5V )
( REMOTE SIGNAL )
( GND )
( MANUAL AUTO SWITCH )
D206
EMPG3863X-J300K GREEN
D208
EBR3864X-J300K RED
TO MAIN PCB
2008.12.11 21
CEILING TYPE
INDOOR UNIT
INDICATOR PCB ASSEMBLY
K04EI-0801HSE-D0
