2013.04.19 6
282 mm
185 mm
870 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LUCA
ASYG09LUCA
ASYG12LUCA
ASYG14LUCA
Drain hose length : 600 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LJCA
ASYG09LJCA
ASYG12LJCA
205 : Installed state
*1: Vertical flap is downward
203 mm
140 *1
10 *1
145 *1
790 mm
280 mm
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LMCA
ASYG09LMCA
ASYG12LMCA
ASYG14LMCA
268 mm
15.8 to 16.7
203 mm840 mm
Drain hose
Diameter
Outside
Inside : 13.8 mm
600 mm
