Installation
Fresh air inlet position
Flexible duct (Locally purchased)
Round duct and the fastening screws (M4)
(Locally purchased)
NOTE: When taking in the fresh air, thermal insulation is required to avoid the product malfunction
caused by dew condensation.
- 32 -
5-3. Fresh air characteristics 5. Fan performance
CEILING TYPE
ABYG18-45KRTA
CEILING TYPE
ABYG18-45KRTA
