2-2. Outdoor unit
¢
Models: AOYG18KBTB and AOYG22KBTB
Unit: mm
Side view
Side view
Front view
Bottom view Side view (Valve part)
Top view
580
79919 68 16 290
33 30
109
353
632
20
330
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
Airflow
Drain port Ø42
37
120
184
399 180
2-2. Outdoor unit - (01-14) - 2. Dimensions
