Models: ABYG24KRTA, ABYG30KRTA, ABYG36KRTA and
ABYG45KRTA
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Insulation 1
Operating manual
(CD-ROM)
1 Drain hose 1
Installation manual 1 Hose band 1
Template 1 Cable tie (large) 4
M10 nut A
(with flange)
4 Cable tie (small) 1
M10 nut B
(with spring lock
washer)
4
Remote controller cable
hole cap
1
Washer 8 Tapping screw (White) 6
Coupler heat insulation
(large)
1 Casing guard 1
Coupler heat insulation
(small)
1 Tapping screw 3
4-2. Outdoor unit
¢
Models: AOYG18KBTB, AOYG22KBTB, and AOYG24KBTB
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain pipe 1
¢
Models: AOYG30KBTB, AOYG36KBTB, and AOYG45KBTB
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain cap 3
Drain pipe 1 One-touch bush 2
4-1. Indoor unit - (02-25) - 4. Accessories
