Fujitsu AOYG54LETL User Manual

2
P A R T S
3
14
8
15
12
13
5
6
4
7
10
1
INDOOR UNIT
162012.04.12
(Connector : black)
11
12 Drain Pan Assy
11 Pipe Thermistor
7 Sirocco Fan
6 Casing B
5 Casing A
2 Kit (Panel Front Sub Assy)
9372579015
9703297113
9372057018
9372059029
9372058015
4 Motor, Induct 9602802012
9372637029
15 Drain Pan S Sub Assy
13 Kit (Panel Right Sub Assy) 9372916025
9372582015
14 Kit (Panel Left Sub Assy)
8 Kit (Panel Rear Sub Assy)
3 Panel Fan Assy
9372581018
9372035009
10 Evaporator Sub Assy 9372584057
9372636022
1 Plate Top Sub Assy 9372576014
Description Parts numberRef.
(Connector : white)
9
9 Room Thermistor 9703299216
