Fujitsu ARG36ELC3 User Manual

Ref.
No.
Description
ARG36ELC3
ARY36ELC3
Ord.
Q'ty
Part No. Part No.
W hen you order parts , please make a photocopy of this page
and fill the num ber of the parts in the "Order" colum n.
PARTS LIS T
34 Capacitor (Fan Motor) 9704305053 9700468042
36-2 Cord Holder Metal 9356362008 9356362008
56 Sirocco Fan Assy 9356531022 9356531022
57 Hex. Socket Screw 313616213202 313616213202
64 Cabinet-Left Metal 9356551006 9356551006
67 Rubber (Vibration-proof) 313659068604 313659068604
69 Cabinet-Right Metal 9356547009 9356547009
74 Intake Panel 9356537000 9356537000
75 Outlet Panel Assy 9356538007 9356538007
108 Base Assy 9356518009 9356518009
109 Casing Assy 9356527001 9356527001
126 Motor Fixing Table Assy 9356533002 9356533002
138 Separate Wall 9356523003 9356523003
143 Clamp NK-3N 313361274700 313361274700
146 Evaporator Assy 9364732008 9364732008
160 Drain Pan Assy 9356542028 9356542028
164 Fan Motor Assy 9600830017 9600830017
173 Hanger Bracket 9356563009 9356563009
184-1 Thermo Spring A 313728262708 313728262708
185-1 Rubber Bushing 9357376004 9357376004
187 Clamp No.1219 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805
196-1 Clamp SKB-3M 312300787605 312300787605
INDOOR U N IT
Ref.
No.
Ord.
Q'ty
234 Thermistor Assy 9703299056 9703299056
235 Thermistor Assy-Pipe 9703297045 9703297045
236 Controller PCB Assy 9704557056 9704557056
240 Remote Control Unit 9703173066 9703173066
287 Cap (Power) 9352173011 9352173011
324 Top Plate 9356546002 9356546002
329 Coupling Pipe Assy 9364734002 9364734002
338 Motor Fixture 9356536003 9356536003
381 Locking Spacer 313209391506 313209391506
394 Pipe Fixing Plate 9356554007 9356554007
448 Control Box Metal-B 9356560008 9356560008
466 Clamp NK-4N 313714328805 313714328805
735 Distributor Assy 9364733005 9364733005
764 Drain Cap 9356541007 9356541007
815 Terminal-7P 9703403019 9703403019
875 9704561053 9704561053
924 Intake Seal Plate
Power PWB Assy
9356553000 9356553000
955 Square Flange Assy 9356555004 9356555004
956 Control Box Metal-E 9356900002 9356900002
574-1 Eva. Fixing Plate-R 9356521009 9356521009
574-2 Eva. Fixing Plate-L 9356522006 9356522006
628 Locking Spacer 313005446558 313005446558
959 Eva. Seal Plate 9356540000 9356540000
968 Relay PCB Assy 9701594030 9701594030
- 14 -2003.09.29
ARG45ELC3
ARY45ELC3
ARG45ELC3
ARY45ELC3
Description
ARG36ELC3
ARY36ELC3
223 Control Box Metal Assy 9356558005 9356558005
