INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF, ASU9RLF, ASU12RLF
622011.03.18
WALL MOUNTED
ASU18RLF
Name and Shape Q’ty
Wall hook bracket
1
Remote control
1
Battery
2
Name and Shape Q’ty
Wall hook bracket
1
Remote control
1
Battery
2
Remote control
holder
1
Remote control
holder
1
Cloth tape
1
Tapping screw
(big)
8
Tapping screw
(small)
2
Air cleaning filter
2
Drain hose insulation
1
Cloth tape
1
Tapping screw (big)
8
Tapping screw
(small)
2
Air cleaning filter
2
Air cleaning filter frame
2
