Fujitsu ARU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 12,000 Btu
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 15.12 11.76 0.69 17.08 11.74 0.70 18.01 12.95 0.71 19.28 13.59 0.72 20.61 13.90 0.73 21.25 15.45 0.73
23 14.49 11.47 0.78 16.37 11.45 0.80 17.26 12.64 0.80 18.48 13.26 0.81 19.75 13.57 0.82 20.36 15.08 0.83
32 14.24 11.35 0.86 16.09 11.34 0.88 16.96 12.51 0.89 18.16 13.12 0.90 19.41 13.43 0.91 20.01 14.92 0.91
41 14.11 11.29 0.89 15.95 11.28 0.90 16.81 12.44 0.91 18.00 13.06 0.92 19.24 13.36 0.93 19.83 14.85 0.94
50 14.24 11.35 0.90 16.09 11.34 0.92 16.96 12.51 0.92 18.16 13.12 0.93 19.41 13.43 0.94 20.01 14.92 0.95
59 14.22 11.35 0.99 16.07 11.33 1.00 16.94 12.50 1.01 18.14 13.12 1.02 19.39 13.42 1.04 19.99 14.92 1.04
67 17.63 12.90 1.43 19.92 12.89 1.46 21.00 14.22 1.47 22.48 14.92 1.49 24.03 15.26 1.50 24.78 16.96 1.51
77 16.91 12.54 1.47 19.11 12.53 1.49 20.14 13.82 1.50 21.56 14.50 1.52 23.05 14.84 1.54 23.76 16.49 1.55
87 15.87 12.04 1.63 17.93 12.02 1.66 18.90 13.26 1.67 20.24 13.92 1.69 21.63 14.24 1.71 22.30 15.83 1.72
95 16.46 12.35 2.03 18.61 12.34 2.07 19.61 13.61 2.09 21.00 14.28 2.11 22.45 14.61 2.13 23.14 16.24 2.15
104 15.01 11.71 2.03 16.97 11.69 2.07 17.89 12.90 2.09 19.15 13.54 2.11 20.47 13.85 2.13 21.10 15.39 2.15
115 12.17 10.68 1.86 13.76 10.67 1.89 14.50 11.77 1.90 15.53 12.35 1.93 16.60 12.64 1.95 17.11 14.05 1.96
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 4.43 3.45 0.69 5.01 3.44 0.70 5.28 3.80 0.71 5.65 3.98 0.72 6.04 4.08 0.73 6.23 4.53 0.73
-5.0 4.25 3.36 0.78 4.80 3.36 0.80 5.06 3.70 0.80 5.42 3.89 0.81 5.79 3.98 0.82 5.97 4.42 0.83
0.0 4.17 3.33 0.86 4.72 3.32 0.88 4.97 3.67 0.89 5.32 3.85 0.90 5.69 3.94 0.91 5.86 4.37 0.91
5.0 4.14 3.31 0.89 4.67 3.31 0.90 4.93 3.65 0.91 5.27 3.83 0.92 5.64 3.92 0.93 5.81 4.35 0.94
10.0 4.17 3.33 0.90 4.72 3.32 0.92 4.97 3.67 0.92 5.32 3.85 0.93 5.69 3.94 0.94 5.86 4.37 0.95
15.0 4.17 3.33 0.99 4.71 3.32 1.00 4.97 3.66 1.01 5.32 3.84 1.02 5.68 3.93 1.04 5.86 4.37 1.04
19.4 5.17 3.78 1.43 5.84 3.78 1.46 6.15 4.17 1.47 6.59 4.37 1.49 7.04 4.47 1.50 7.26 4.97 1.51
25.0 4.96 3.68 1.47 5.60 3.67 1.49 5.90 4.05 1.50 6.32 4.25 1.52 6.76 4.35 1.54 6.97 4.83 1.55
30.6 4.65 3.53 1.63 5.26 3.52 1.66 5.54 3.89 1.67 5.93 4.08 1.69 6.34 4.17 1.71 6.54 4.64 1.72
35.0 4.83 3.62 2.03 5.45 3.62 2.07 5.75 3.99 2.09 6.15 4.19 2.11 6.58 4.28 2.13 6.78 4.76 2.15
40.0 4.40 3.43 2.03 4.97 3.43 2.07 5.24 3.78 2.09 5.61 3.97 2.11 6.00 4.06 2.13 6.19 4.51 2.15
46.1 3.57 3.13 1.86 4.03 3.13 1.89 4.25 3.45 1.90 4.55 3.62 1.93 4.86 3.70 1.95 5.01 4.12 1.96
 Indoor units: 9,000 Btu + 9,000 Btu
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 14.72 11.60 0.66 16.63 11.58 0.67 17.53 12.78 0.68 18.77 13.41 0.69 20.07 13.72 0.70 20.69 15.24 0.70
23 14.10 11.31 0.75 15.94 11.30 0.76 16.80 12.46 0.77 17.99 13.08 0.78 19.23 13.38 0.79 19.82 14.87 0.79
32 13.86 11.20 0.83 15.66 11.19 0.84 16.51 12.34 0.85 17.68 12.95 0.86 18.90 13.25 0.87 19.48 14.72 0.87
41 13.74 11.14 0.85 15.52 11.13 0.87 16.36 12.27 0.87 17.52 12.88 0.88 18.73 13.18 0.89 19.31 14.65 0.90
50 13.86 11.20 0.86 15.66 11.19 0.88 16.51 12.34 0.88 17.68 12.95 0.89 18.90 13.25 0.90 19.48 14.72 0.91
59 14.22 11.37 1.00 16.07 11.35 1.02 16.94 12.52 1.03 18.14 13.14 1.04 19.39 13.45 1.05 19.99 14.94 1.06
67 16.60 12.49 1.28 18.76 12.47 1.30 19.78 13.76 1.31 21.17 14.44 1.33 22.63 14.77 1.34 23.33 16.42 1.35
77 15.92 12.14 1.31 17.99 12.12 1.33 18.97 13.37 1.34 20.31 14.03 1.36 21.71 14.36 1.37 22.38 15.96 1.38
87 14.94 11.65 1.45 16.89 11.64 1.48 17.80 12.83 1.49 19.06 13.47 1.51 20.37 13.78 1.52 21.00 15.31 1.53
95 16.46 12.38 2.06 18.61 12.36 2.10 19.61 13.63 2.12 21.00 14.31 2.14 22.45 14.64 2.15 23.14 16.27 2.15
104 14.91 11.69 2.06 16.85 11.67 2.10 17.77 12.87 2.12 19.02 13.51 2.14 20.33 13.82 2.15 20.96 15.36 2.15
115 12.04 10.65 1.88 13.60 10.64 1.92 14.34 11.73 1.93 15.35 12.31 1.95 16.41 12.60 1.98 16.92 14.00 1.99
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 4.31 3.40 0.66 4.87 3.39 0.67 5.14 3.74 0.68 5.50 3.93 0.69 5.88 4.02 0.70 6.06 4.47 0.70
-5.0 4.13 3.32 0.75 4.67 3.31 0.76 4.92 3.65 0.77 5.27 3.83 0.78 5.64 3.92 0.79 5.81 4.36 0.79
0.0 4.06 3.28 0.83 4.59 3.28 0.84 4.84 3.62 0.85 5.18 3.79 0.86 5.54 3.88 0.87 5.71 4.31 0.87
5.0 4.03 3.27 0.85 4.55 3.26 0.87 4.80 3.60 0.87 5.13 3.78 0.88 5.49 3.86 0.89 5.66 4.29 0.90
10.0 4.06 3.28 0.86 4.59 3.28 0.88 4.84 3.62 0.88 5.18 3.79 0.89 5.54 3.88 0.90 5.71 4.31 0.91
15.0 4.17 3.33 1.00 4.71 3.33 1.02 4.97 3.67 1.03 5.32 3.85 1.04 5.68 3.94 1.05 5.86 4.38 1.06
19.4 4.87 3.66 1.28 5.50 3.66 1.30 5.80 4.03 1.31 6.21 4.23 1.33 6.63 4.33 1.34 6.84 4.81 1.35
25.0 4.67 3.56 1.31 5.27 3.55 1.33 5.56 3.92 1.34 5.95 4.11 1.36 6.36 4.21 1.37 6.56 4.68 1.38
30.6 4.38 3.41 1.45 4.95 3.41 1.48 5.22 3.76 1.49 5.59 3.95 1.51 5.97 4.04 1.52 6.16 4.49 1.53
35.0 4.83 3.63 2.06 5.45 3.62 2.10 5.75 4.00 2.12 6.15 4.19 2.14 6.58 4.29 2.15 6.78 4.77 2.15
40.0 4.37 3.42 2.06 4.94 3.42 2.10 5.21 3.77 2.12 5.57 3.96 2.14 5.96 4.05 2.15 6.14 4.50 2.15
46.1 3.53 3.12 1.88 3.99 3.12 1.92 4.20 3.44 1.93 4.50 3.61 1.95 4.81 3.69 1.98 4.96 4.10 1.99
- 188 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU18RLXFZ OUTDOOR UNIT AOU18RLXFZ

Fujitsu ARU18RLF Specifications

General

Brand	Fujitsu
Model	ARU18RLF
Category	Air Conditioner
Language	English
