 Indoor units: 9,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 14.87 1.95 14.40 2.01 13.91 2.06 13.42 2.12 13.13 2.15
14 12 16.78 1.97 16.25 2.03 15.70 2.09 15.15 2.15 14.82 2.15
23 19 18.86 1.97 18.26 2.03 17.65 2.09 17.03 2.15 16.65 2.15
32 28 21.59 1.94 20.91 2.00 20.20 2.05 19.49 2.11 19.06 2.15
41 37 24.45 1.91 23.68 1.96 22.88 2.02 22.08 2.07 21.59 2.11
47 43 26.08 1.98 25.25 2.04 24.40 2.10 23.55 2.15 23.03 2.15
50 47 26.27 1.97 25.44 2.03 24.58 2.09 23.72 2.15 23.20 2.15
59 50 26.53 1.96 25.69 2.02 24.83 2.07 23.96 2.13 23.43 2.15
68 59 26.01 1.57 25.19 1.62 24.34 1.66 23.49 1.71 22.97 1.74
75 65 24.12 1.28 23.36 1.31 22.57 1.35 21.78 1.39 21.30 1.41
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.36 1.95 4.22 2.01 4.08 2.06 3.93 2.12 3.85 2.15
-10.0 -11.1 4.92 1.97 4.76 2.03 4.60 2.09 4.44 2.15 4.34 2.15
-5.0 -7.2 5.53 1.97 5.35 2.03 5.17 2.09 4.99 2.15 4.88 2.15
0.0 -2.2 6.33 1.94 6.13 2.00 5.92 2.05 5.71 2.11 5.59 2.15
5.0 2.8 7.17 1.91 6.94 1.96 6.71 2.02 6.47 2.07 6.33 2.11
8.3 6.1 7.64 1.98 7.40 2.04 7.15 2.10 6.90 2.15 6.75 2.15
10.0 8.3 7.70 1.97 7.46 2.03 7.20 2.09 6.95 2.15 6.80 2.15
15.0 10.0 7.78 1.96 7.53 2.02 7.28 2.07 7.02 2.13 6.87 2.15
20.0 15.0 7.62 1.57 7.38 1.62 7.13 1.66 6.88 1.71 6.73 1.74
23.9 18.3 7.07 1.28 6.85 1.31 6.61 1.35 6.38 1.39 6.24 1.41
- 194 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT
AOU18RLXFZ
OUTDOOR UNIT
AOU18RLXFZ
