Models: ASHG18KMTE, ASHG22KMTE, and ASHG24KMTE
Unit: mm
for pipe inlet Ø65
50
60
430
52
980 240
280
Outline of indoor unit
for pipe inlet Ø65
400413 9077
50
72
418
91
417
482
510
2-5. Wall mounted type - (01-39) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
