2-5. Floor type
¢
Models: AGHG09KVCA, AGHG12KVCA, and AGHG14KVCA
600
200
Side view
Front view
740
Unit: mm
2-5. Floor type - (01-30) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
