Fujitsu ARXG14KLLAP - Page 525

Model: ARXG18KLLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.39 4.29 4.19 4.08 3.98
-10.0 -11.0 5.10 4.98 4.86 4.74 4.62
-5.0 -7.0 5.39 5.26 5.13 5.00 4.87
0.0 -2.0 6.17 6.02 5.87 5.73 5.58
5.0 3.0 7.09 6.92 6.75 6.58 6.41
7.0 6.0 7.09 6.92 6.75 6.58 6.41
10.0 8.0 7.09 6.92 6.75 6.58 6.41
15.0 10.0 7.09 6.92 6.75 6.58 6.41
20.0 15.0 7.09 6.92 6.75 6.58 6.41
24.0 18.0 7.09 6.92 6.75 6.58 6.41
NOTES:
• TC: Total Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)

Medium static pressure duct type
Model: ARXG22KMLB
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 5.55 5.41 5.28 5.15 5.02
-10.0 -11.0 6.44 6.29 6.13 5.98 5.83
-5.0 -7.0 6.80 6.64 6.48 6.31 6.15
0.0 -2.0 7.78 7.60 7.41 7.23 7.04
5.0 3.0 8.95 8.73 8.52 8.31 8.09
7.0 6.0 8.95 8.73 8.52 8.31 8.09
10.0 8.0 8.95 8.73 8.52 8.31 8.09
15.0 10.0 8.95 8.73 8.52 8.31 8.09
20.0 15.0 8.95 8.73 8.52 8.31 8.09
24.0 18.0 8.95 8.73 8.52 8.31 8.09
Model: ARXH22KMTAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 5.55 5.41 5.28 5.15 5.02
-10.0 -11.0 6.44 6.29 6.13 5.98 5.83
-5.0 -7.0 6.80 6.64 6.48 6.31 6.15
0.0 -2.0 7.78 7.60 7.41 7.23 7.04
5.0 3.0 8.95 8.73 8.52 8.31 8.09
7.0 6.0 8.95 8.73 8.52 8.31 8.09
10.0 8.0 8.95 8.73 8.52 8.31 8.09
15.0 10.0 8.95 8.73 8.52 8.31 8.09
20.0 15.0 8.95 8.73 8.52 8.31 8.09
24.0 18.0 8.95 8.73 8.52 8.31 8.09
NOTES:
• TC: Total Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 517 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
