4-6. Pressure switch
¢ Models: AOYG45KRTA and AOYG54KRTA
• Type of contact
C
H
Pressure
• Characteristics of pressure switch
Pressure switch 1
Contact: Short  Open 4.2 — 4.05 MPa
Contact: Open  Short 3.2 ± 0.15 MPa
45/54 model: P770
4-6. Pressure switch - (03-56) - 4. Service parts information
