Refrigerant pipe
12.7mm(1/2")
Refrigerant pipe
6.35mm(1/4")
Capillary tube
Charging valve
Compressor
OUTDOOR UNITINDOOR UNIT
Strainer
Evaporator
Condenser
INDOOR UNIT
Refrigerant pipe
6.35mm(1/4")
Refrigerant pipe
12.7mm(1/2")
Capillary
tube
Strainer
Strainer
OUTDOOR UNIT
Condenser
Compressor
4-Way
Muffler
valve
Charging valve
Evaporator
Distributor
Models : ARY14FUAD / AOY14FSDJ
Models : ARY14UUAD / AOY14USDJL
Strainer
Cooling
Heating
: Flare coupling
62006.03.23
