Refrigerant pipe
9.52mm(3/8")
Refrigerant pipe
6.35mm(1/4")
Capillary tube
Charging valve
Compressor
OUTDOOR UNITINDOOR UNIT
Strainer
Evaporator
Condenser
INDOOR UNIT
Refrigerant pipe
6.35mm(1/4")
Refrigerant pipe
9.52mm(3/8")
Capillary
tube
Strainer
OUTDOOR UNIT
Condenser
Compressor
4-Way
Muffler
valve
Charging valve
Evaporator
Distributor
Models : ARY12FUAD / AOY12FSAJ
Models : ARY12UUAD / AOY12USAJL
REFRIGERANT SYSTEM DIAGRAM
Strainer
Cooling
Heating
: Flare coupling
52006.03.23
