SPECIFICATIONS
HIGH
1,200 r.p.m.
FAN SPEED
INDOOR MED
1,120 r.p.m.
LOW
1,030 r.p.m.
OUTDOOR
780 r.p.m.
AIR FLOW
INDOOR
1,100 m
3
/hr
OUTDOOR
INDOOR
OUTDOOR
3,200 m
3
/hr
DIMENSIONS
INDOOR
270 x 1,135 x 700 mm
H x W x D
OUTDOOR
650 x 830 x 320 mm
WEIGHT
43 kg / 50 kg
58 kg / 62 kg 59 kg / 63 kg
MAX PIPE LENGTH
25 m
MAX PIPE HEIGHT
15 m
REMOTE CONTROLLER TYPE
WIRED
NET / GROSS
HEATING CAPACITY
POWER SOURCE
FREQUENCY
RUNNING CURRENT
COOLING
HEATING
INPUT WATTS
COOLING
HEATING
E.E.R.
COOLING
HEATING
3.30 kW/kW
MOISTURE REMOVAL
ARY25FUAN ARY25UUAN
AOY25FNAKL
AOY25FNANL
AOY25UNAKL
AOY25UNANL
7.05 kW 7.00 kW
------
------
------
------
7.70 kW
TYPE
COOLING COOL & HEAT
INDOOR UNIT
OUTDOOR UNIT
COOLING CAPACITY
230 V
50 Hz
ELECTRICAL DATA
COMPRESSOR
DISCRIMINATION
11.5 A
11.8 A
10.5 A
2.60 kW 2.65 kW
2.33 kW
2.71 kW/kW 2.64 kW/kW
STARTING CURRENT
60 A
2.5 L/hr
MFA-30PTT
Note :
The above list shows values at the external static pressure of
98Pa (10mm Ag), setting the fan speed high notch.
Note :
The above list shows values at the external static pressure of
98Pa (10mm Ag), setting the fan speed high notch.
7.5 m
(24 ft.)
10 m
(33 ft.)
15 m
(49 ft.)
20 m
(66 ft.)
25 m
(82 ft.)
20 g / m
(0.212 oz / ft.)
1,550 g
(54.7 oz)
1,600 g
(56.4 oz)
1,700 g
(60.0 oz)
1,800 g
(63.5 oz)
1,900 g
(67.0 oz)
2,000 g
(70.6 oz)
2,100 g
(74.1 oz)
2,300 g
(81.1 oz)
2,500 g
(88.2 oz)
2,700 g
(95.2 oz)
40 g / m
(0.424 oz / ft.)
ADDITIONAL REFRIGERANT
FULL CHARGE
When you dismantle indoor units which are installed,
take care not to make parts fall down, especially motors.
NOISE LEVEL
REFRIGERANT CHARGE (R410A)
INDOOR UNIT
HI-SPEED
38 dB
MED-SPEED
COOLING
HEATING
36 dB
LO-SPEED
34 dB
----
OUTDOOR UNIT
54 dB
53 dB 53 dB
Note : Static pressure : 100Pa
Duct length : Inlet 1m, Outlet 2m
Pipe Length
TYPE
DISCRIMINATION
REFRIGERANT R410A
Hermetic type, 2 pole,
Single phase,
Induction motor, Rotary
5JS290DAA
1,550 g 2,000 g
2006.03.09 1
To Next Page
