5. CONTROL SYSTEM
ELECTRICAL WIRING

1 remote controller


2 remote controllers
1 (RED) : 1 2V
2 (WHITE) : Signal
3 (BLACK) : COM
Indoor unit
REMOTE
CONTROLLER
123
123
Primary
Secondary
Indoor unit
123
123 123
REMOTE
CONTROLLER
Remote controller Remote controllers
DIMENSIONS

120
75
49
39
23.5
14
4
11
4.5
12.5
hole x 2
hole x 2
8
60
6
18
9
47.5
83.5
Front View Side View Rear View
[Unit : mm]
- (05 - 33) -
CONTROL SYSTEM CONTROL SYSTEM
