Fujitsu ASU9R1A - Outline and Dimensions

Models : ASU9R1A / AOU9R1
ASU12R1A / AOU12R1
32-1/8” (815) 7 (179)
11 (280)
– 2 –
OUTLINE AND DIMENSIONS
INDOOR UNIT
Unit : inch (mm)
OUTDOOR UNIT
30-1/2” (750)
19-13/32” (493)
20-7/8” (530)
33/64” (13)
9-7/8” (250)
11-7/32” (285)
(Bolt pitch for installation)
