Fujitsu ASU9R2 User Manual

33
24
34
27
29
28
30
31
32
INDOOR UNIT
Control box
2010.11.16 12
23
22
21
26
25
28 Gear A
33 Crossflow Fan Assy
34 Bearing C Assy
25 Controller PCB Assy (9)
25 Controller PCB Assy (12) 9705712065
27 Stepping Motor
30 Fan Motor
Ref. Description Part number
9309994003
24 Switch Box Assy 9314245015
23 Switch Cover 9313943011
26 Terminal 9701955114
21 Wire Clamper 9313944018
22 Connector Cover 9313945015
9307836015
9306628017
9705712058
9900139025
9601846017
31 Motor Cushion N 9312979011
32 Motor Cushion NR 9313168018
29 Motor Clamp 9313724016
