2
DIMENSIONS
INDOOR UNIT
Unit : inch (mm)
OUTDOOR UNIT
Drain hose length : 22-27/32 inch (580 mm)
31-1/8 (790)
2-3/16 (56)
11/16
(17)
21-1/4 (540)
14 (356)
11-7/16 (290)
8-15/32 (215)
31-1/8 (790)
10-13/16 (275)
11-3/16 (288)
2010.12.10
