Page #15 background imageLoading...
Page #15 background image
54
53
52
55
56
51
INDOOR UNIT
Evaporator
2010.11.16 14
Evaporator Holder L Assy
Joint Pipe Assy
Evaporator Holder R
Evaporator Total Assy
Evaporator Bracket
Water Seal
52
51
54
55
53
56
9314241024
9331471015
9312360024
9309983014
9312912018
9310464007
Ref. Description Part number
