OUTDOOR UNIT
PARTS
212007.10.31
3
5
2
4
1
6
9
7
1 Top Panel Sub Assy
2 Front Panel M
3 Fan Guard
4 Grip Side
5 Service Panel Sub Assy
6 Right Panel M
7 Valve Cover Sub Assy
9 Grip
9374417025
9374094066
9374330010
9374173013
9374415038
9374599066
9374827015
9374172016
Ref. Description Part number
