Item no. Part no. Part name Service part

1 9388142005 Bracket panel ♦

2 9387471007 Louver spring ♦

3 9333608006 Bush ♦

4 9313951047 Conduit holder ♦

5 9387714036 Step motor holder assy ♦

6 9901011047 Step motor ♦

7 9332861006 Shaft cover ♦

8 9387590166 Drain pan total assy ♦

9 9387476002 Screw cover ♦

10 9387479003 U/D louver assy ♦

11 9387597035 Wire cover assy ♦

12 9387478044 Under cover R ♦

13 9387596984 Front panel total assy ♦

14 9333704005 Grille clamper R ♦

15 9387756227 Intake grill total assy ♦

16 9333719009 Grille clamper L ♦

17 9387473001 Air filter ♦

18 9387477047 Under cover L ♦

19 9316177017 Drain cap ♦

20 9316904002 Drain hose assy ♦

21 9334098004 Remote controller holder ♦

22 9334126004 Remote controller ♦

23 9351596002 Remote controller total assy ♦

a — Step motor holder —

b — Front panel —

2-1. Models: ASUH09LPAS and ASUH12LPAS - (02-3) - 2. Indoor unit parts list
