Item no. Part no. Part name Service part

50 9387587128 Base assy ♦

51 9383765056 WLAN adapter holder assy ♦

9711732040 Main PCB (For 09 model) ♦

9711732057 Main PCB (For 12 model) ♦

53 9387488043 Cable guide ♦

54 9711146076 Display assy ♦

55 9711147011 Indicator PCB ♦

56 9901013010 Terminal ♦

57 9603821012 Brushless motor ♦

58 9387589061 Motor case assy ♦

59 9317250009 Air clean filter assy ♦

60 9332911008 Electric filter holder ♦

9387593389 Evaporator total assy (For 09 model) ♦

9387593396 Evaporator total assy (For 12 model) ♦

62 9900627041 Thermistor assy ♦

63 9387467000 Room thermistor holder ♦

64 9333628004 Bearing D assy ♦

65 9387055047 Crossflow fan assy ♦

a — Box shield —

b — Control box —

c — PCB holder A —

d — Control cover —

e — Display case assy —

f — Motor case —

g — Motor cover

2-1. Models: ASUH09LPAS and ASUH12LPAS - (02-5) - 2. Indoor unit parts list
