Fujitsu ASUH12LPAS Service Manual

1. Specifications
1-1. Indoor unit
Type
Wall mounted
Inverter heat pump
Model name ASUH09LPAS ASUH12LPAS
Power supply 208/230 V ~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 2.64 3.52
Btu/h 9,000 12,000
Min.—Max.
kW 0.97—3.16 1.00—3.72
Btu/h 3,300—10,800 3,400—12,700
Heating
Rated
kW 2.93 4.10
Btu/h 10,000 14,000
Min.—Max.
kW 0.77—3.66 0.91—4.98
Btu/h 2,600—12,500 3,100—17,000
Heating (17°F)*
1
Rated
kW 1.82 2.58
Btu/h 6,200 8,800
Max.
kW 2.49 3.34
Btu/h 8,500 11,400
Heating (5°F)*
2
Rated
kW 1.96 2.99
Btu/h 6,700 10,200
Max.
kW 1.96 3.00
Btu/h 6,700 10,240
Input power
Cooling
Rated
kW
0.72 1.09
Min.—Max. 0.14—1.18 0.14—1.33
Heating
Rated 0.74 1.10
Min.—Max. 0.13—1.23 0.14—1.61
Heating (17°F)*
1
Rated 0.65 0.85
Max. 1.09 1.34
Heating (5°F)*
1
Rated 0.95 1.30
Max. 0.95 1.30
Current
Cooling
Rated A
3.5 4.9
Heating 3.7 4.9
EER2 Cooling
kW/kW 3.66 3.22
Btu/hW 12.50 11.0
COP2 Heating
kW/kW 3.96 3.72
Btu/hW 13.50 12.70
SEER2 Cooling Btu/hW 20.0
HSPF2 Heating Btu/hW 10.5
Power factor
Cooling
%
89.4 96.7
Heating 86.9 97.6
Moisture removal pints/h (L/h) 2.7 (1.3) 3.8 (1.8)
Maximum operating current*
3
Cooling
A
6.4 6.9
Heating 7.9
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
412 (700) 453 (770)
MED 330 (560) 353 (600)
LOW 253 (430) 265 (450)
QUIET 159 (270) 147 (250)
Heating
HIGH 441 (750) 453 (770)
MED 359 (610) 377 (640)
LOW 277 (470) 306 (520)
QUIET 194 (330) 182 (310)
Type × Qty Crossflow fan × 1
Motor output W 49
Sound pressure level*
4
Cooling
HIGH
dB (A)
40 43
MED 34 36
LOW 29 30
QUIET 19
Heating
HIGH 42 43
MED 36 38
LOW 31 33
QUIET 21
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 26-5/16 × 1-1/16
(210 × 688 × 26.6)
Main2: 4-7/16 × 26-5/16 × 13/16
(112 × 688 × 20)
Main1: 8-1/4 × 26-5/16 × 1-1/16
(210 × 688 × 26.6)
Main2: 4-7/16 × 26-5/16 × 13/16
(112 × 688 × 20)
Sub: 3-5/16 × 26-5/16 × 1/2
(84 × 688 × 13.3)
Fin pitch FPI
Man1: 21
Main2: 23
Man1: 21
Main2: 23
Sub: 18
Rows × Stages
Main1: 2 × 10
Main2: 2 × 7
Main1: 2 × 10
Main2: 2 × 7
Sub: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
10-5/8 × 32-13/16 × 8-3/4 (270 × 834 × 222)
Gross 10-7/8 × 36 × 13-1/16 (277 × 914 × 332)
Weight
Net
lb (kg)
21 (9.5) 22 (10.0)
Gross 26 (12.0) 29 (13.0)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52)
Method Flare
1-1. Indoor unit - (01-1) - 1. Specifications
