2-2. Outdoor unit

Models: AOUH18LPAS1 and AOUH24LPAS1

Side viewSide view

Front view

Top view

22-13/16 (580)

31-7/16 (799)3/4 (19) 2-11/16 (68) 1/2 (13) 11-7/16 (290)

1-5/16 (33) 1-3/16 (30)

4-5/16 (109)

13-7/8 (353)

24-7/8 (632)

13/16 (20)

13 (330)

Pitch of bolts

for installation

Pitch of bolts for installation

0 hole

Unit: in (mm)

Side view (Valve part)

4-3/4 (120)

4-1/4 (184)

7-1/16 (180)

Bottom view

Airflow

Drain port Ø1-5/8 (42)

1-7/16 (37)

15-11/16 (399)

2-2. Outdoor unit - (01-6) - 2. Dimensions
