Item no. Part no. Part name Service part
1 9322556028 Top panel assy ♦
2 9322811028 Protective net assy ♦
3 9322552242 Cabinet right assy ♦
4 9384276001 Conduit cover ♦
5 9322570062 Switch cover assy ♦
6 9322314024 Base assy ♦
7 9322144003 Drain pipe ♦
8
9709686348 Main PCB (for 18 model) ♦
9709686355 Main PCB (for 24 model) ♦
9 9900935054 Thermistor assy ♦
10 9900985011 Thermistor assy (Compressor temp.) ♦
11 9900565060 Thermistor assy (Outdoor temp.) ♦
12 9322420053 Heat sink ♦
13 9810028006 Thermistor stopper ♦
14 9317903011 Emblem ♦
15 9384273000 Fan Guard ♦
16 9322555182 Front panel assy ♦
17 9322150004 Propeller fan ♦
18 9603601003 Brushless motor ♦
19 9322553027 Motor bracket assy ♦
20 9323834286 Heat exchanger unit ♦
a — Inverter assy —
b — Hair pin cushion —
3-1. Models: AOUH18LPAS1 and AOUH24LPAS1 - (02-7) - 3. Outdoor unit parts list
