R E F R I G E R A N T
S Y S T E M D I A G R A M
A Unit
B Unit
heat exchanger
(Indoor)
heat exchanger
(Outdoor)
3-way
valve
2-way
valve
accumulator
compresser
4-way valve
COMP
electric
expansion
valve
strainer
strainer
receiver tank
EVA
EVB
HEAT
COOL
42005.08.19
