CASSETTE TYPE
AUU42R
CASSETTE TYPE
AUU42R
- (04 - 02) -
Fresh air can be introduced through this opening.
Duct connection hole opening
Conditioned air can be distributed by means of a distribution duct.
Distribution
duct
Distribution
duct
Fresh air
One-way
Two-way
