Item no. Part no. Part name Service part

9387587098 Base assy (for 07-14KETA model) ♦

9387587104 Base assy (for 07-14KETA-B model) ♦

51 9383765032 WLAN adapter holder assy ♦

9711141590 Main PCB (for 07 model) ♦

9711141606 Main PCB (for 09 model) ♦

9711141613 Main PCB (for 12 model) ♦

9711141620 Main PCB (for 14 model) ♦

53 9711382009 Display assy ♦

54 9711358004 Display PCB ♦

55 9900369057 Terminal ♦

9603768003 Brushless motor (for 07-12 model) ♦

9603631017 Brushless motor (for 14 model) ♦

57 9387589061 Motor case assy ♦

58 9317250009 Air clean filter assy ♦

59 9332911008 Electric filter holder ♦

9387593143 Evaporator total assy (for 07-12 model) ♦

9387593150 Evaporator total assy (for 14 model) ♦

61 9900627041 Thermistor assy ♦

62 9387467000 Room thermistor holder ♦

63 9333628004 Bearing D assy ♦

64 9387055047 Crossflow fan assy ♦

a — Box shield —

b — Control box —

c — PCB holder A —

d — Motion sensor —

e — Front panel cover B assy —

f — Display case assy —

g — Control cover —

h — Motor case —

i — Motor cover —

3-5. Wall mounted type - (02-71) - 3. Indoor unit parts list
