Item no. Part no. Part name Service part

9387587098 Base assy (for 07-14KETA model) ♦

9387587104 Base assy (for 07-14KETA-B model) ♦

51 9383765056 WLAN adapter holder assy ♦

9711732293 Main PCB (for 07 model) ♦

9711732309 Main PCB (for 09 model) ♦

9711732316 Main PCB (for 12 model) ♦

9711732323 Main PCB (for 14 model) ♦

53 9387488012 Cable guide ♦

54 9711382009 Display assy ♦

55 9711358004 Display PCB ♦

56 9901013010 Terminal ♦

57 9384500014 Motor case sub assy ♦

9603768003 Brushless motor (for 07-12 model) ♦

9603631017 Brushless motor (for 14 model) ♦

59 9387713022 Motor cover assy ♦

60 9317250009 Air clean filter assy ♦

61 9332911008 Electric filter holder ♦

9387593143 Evaporator total assy (for 07-12 model) ♦

9387593150 Evaporator total assy (for 14 model) ♦

63 9900627041 Thermistor assy ♦

64 9387467000 Room thermistor holder ♦

65 9333628004 Bearing D assy ♦

66 9387055047 Crossflow fan assy ♦

a — Box shield —

b — Control box —

c — PCB holder A —

d — Motion sensor —

e — Front panel cover B assy —

f — Display case assy —

g — Control cover —

3-5. Wall mounted type - (02-75) - 3. Indoor unit parts list
