Item no. Part no. Part name Service part
1 9316193024 Base ♦
2 9316197015 Base cover A ♦
3 9316373013 Base cover B ♦
4 9316405011 Base bracket ♦
5 9316272019 Bracket panel ♦
6 9306628024 Bearing C assy ♦
7 9900720087 Terminal (3P) ♦
8 9316307025 Terminal cover ♦
9 9316186019 Front panel R ♦
10 9316415171 Front panel total assy ♦
11 9316189027 Air filter ♦
12 9316418066 Intake grille assy ♦
13 9316458017 Rope assy ♦
14 9316474017 Air clean filter assy ♦
15 9318912005 Remote controller holder ♦
16 9332438871 Remote controller ♦
17 9316187016 Front panel L ♦
18 9900991005 Pipe thermistor ♦
19 9316091269 Evaporator total assy ♦
20 9316192027 Thermistor holder ♦
21 9316195011 Motor holder ♦
22 9602851003 Fan motor (MFD-14SXN) ♦
23 9316309012 Crossflow fan B assy ♦
24 9602850006 Fan motor (MFD-14TXN) ♦
25 9312004034 Crossflow fan assy ♦
26 9900975067 Room thermistor ♦
27
9711694065 Main PCB (09 model) ♦
9711694072 Main PCB (12 model) ♦
9711694089 Main PCB (14 model) ♦
— 9711684004
Wire with terminal
(Main PCB—Earth)
♦
a — Terminal bracket —
b — Cable bracket —
c — Front panel —
d — Terminal bracket (COM) —
e — Control box shield —
f — Control box cover —
g — Control box —
3-7. Floor type - (02-79) - 3. Indoor unit parts list
