Item no. Part no. Part name Service part
50 9316411012 Casing assy ♦
51 9316207011 Top cover ♦
52 9315281012 Spacer C ♦
53 9316209015 Joint U ♦
54 9316210011 Guard holder ♦
55 9315282019 Spacer D ♦
56 9316208018 L and R louver U ♦
57 9316211018 Fan guard ♦
58 9316310018 Casing cover L and R ♦
59 9312156016 Bushing B ♦
60 9316308015 Casing cover F ♦
61 9316206014 Louver Z ♦
62 9316205017 Louver U ♦
63 9303529010 Bushing A ♦
64 9316213012 Gear case ♦
65 9309994003 Gear A ♦
66 9316273016 Casing cover B ♦
67 9711714008 Display assy ♦
68 9711696007 Indicator PCB ♦
69 9900384043 Step motor (Up/Down) ♦
a — Casing —
b — Casing reinforcement —
c — Display cover —
d — Display case —
e — Switch cover —
3-7. Floor type - (02-81) - 3. Indoor unit parts list
