Item no. Part no. Part name Service part

1 9322556073 Top panel assy ♦

2 9322811066 Protective net ♦

9322552280 Cabinet right assy (For 30 model) ♦

9322552273 Cabinet right assy (For 36 model) ♦

4 9322554031 Terminal cover assy ♦

5 9322570086 Switch cover assy ♦

6 9900369064 Terminal (Power) ♦

7 9900369071 Terminal (Inner) ♦

9711609007 Indicator PCB (For 30 model) ♦

9711609014 Indicator PCB (For 36 model) ♦

9711432339 Main PCB (For 30 model) ♦

9711432346 Main PCB (For 36 model) ♦

10 9900565008 Thermistor assy (Outdoor temp.) ♦

11 9900727185 Thermistor assy ♦

12 9900985028 Compressor thermistor ♦

13 9709685785 Inverter PCB ♦

14 9322421043 Heat sink ♦

15 9322144003 Drain pipe ♦

16 9322322043 Base assy ♦

17 9322386007 Cushion rubber ♦

18 9810028006 Thermistor stopper ♦

19 9319157009 Emblem ♦

20 9322149008 Blow grille ♦

21 9322555274 Front panel assy ♦

22 9322150004 Propeller fan ♦

23 9603601003 DC fan motor ♦

9322553171 Motor bracket assy (For 30 model) ♦

9322553188 Motor bracket assy (For 36 model) ♦

25 9900984045 Thermistor (Heat exchanger) ♦

26 9323834606 Heat exchanger unit (For 30 model) ♦

27 9323834613 Heat exchanger unit (For 36 model) ♦

a — Hair pin cushion —

4-1. Models: AOHG30KBTA4 and AOHG36KBTA5 - (02-85) - 4. Outdoor unit parts list
