Item no. Part no. Part name Service part
1 9377760043 Flap total assy ♦
2 9377759047 Flap assy B ♦
3 9375727048 Flap assy A ♦
4 9375539016 Joint B ♦
5 9375540012 Joint shaft ♦
6 9375746018 Motor holder assy B ♦
7 9900139087 Step motor (with Red connector) ♦
8 9375536015 Gear A ♦
9 9711310002 Indicator PCB ♦
10 9382864040 Display panel ♦
11 9378597013 Hook wire ♦
12 9382862008 Intake grille assy ♦
13 9375533014 Long-life filter ♦
14 9375745011 Motor holder assy A ♦
15 9900139070 Step motor (with White connector) ♦
— 9711276001 Wire with connector ♦
2-1. Model: UTG-UFGF-W - (02-3) - 2. Cassette grille (optional part) parts list
