¢ Models: ASHG07KMCE, ASHG09KMCE, ASHG12KMCE, and
ASHG14KMCE
Unit: mm
344 356
327 11332767
62
50
62
84
43
43
Outline of indoor unit
for pipe inlet Ø65 for pipe inlet Ø65
834 215
3.0
270
359
418
492
2-4. Wall mounted type - (01-26) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION
