16
14
15
11
12
13
Item no. Part no. Part name Service part
12 0600063023 Holder ♦
13 9710019005 Communication PCB ♦
14 9710661006 Power supply PCB ♦
15 9900568009 Terminal ♦
16 9900896003 Terminal ♦
3-1. Compact cassette type - (02-5) - 3. Indoor unit parts list
