Fujitsu AUXG12KVLA Service Manual

¢ Floor type
 Fan speed
Indoor fan speed is defined as below.
• Model: AGHG09KVCA
Operation mode
Fan mode
(Upper/Lower)
Speed (rpm)
Upper & Lower air flow
mode
Upper air flow mode
Heating
POWERFUL 1,230/1,040 1,300/ —
HIGH 1,120/950 1,230/ —
MED+ 1,000/850 1,090/ —
MED 1,000/850 1,090/ —
LOW- 860/730 940/ —
QUIET 660/560 790/ —
Cool air prevention 660/560 790/ —
S-LOW 660/560 790/ —
Cooling/Fan
POWERFUL 1,230/1,040 1,300/ —
HIGH 1,120/950 1,230/ —
MED 960/820 1,070/ —
LOW 820/700 910/ —
QUIET 660/560 790/ —
Soft quiet
570/480*
1
790/ —*
1
S-LOW
660/560*
2
790/ —*
2
Dry
X zone: — / —
J zone: — / —
X zone: 790/ —
J zone: 790/ —
*1: Fan mode only
*2: Cooling mode only
• Model: AGHG12KVCA
Operation mode
Fan mode
(Upper/Lower)
Speed (rpm)
Upper & Lower air flow
mode
Upper air flow mode
Heating
POWERFUL 1,350/1,150 1,370/ —
HIGH 1,240/1,040 1,300/ —
MED+ 1,080/920 1,140/ —
MED 1,080/920 1,140/ —
LOW- 910/770 980/ —
QUIET 660/560 790/ —
Cool air prevention 660/560 790/ —
S-LOW 660/560 790/ —
Cooling/Fan
POWERFUL 1,350/1,150 1,370/ —
HIGH 1,240/1,040 1,300/ —
MED 1,050/890 1,120/ —
LOW 860/730 930/ —
QUIET 660/560 790/ —
Soft quiet
570/480*
1
790/ —*
1
S-LOW
660/560*
2
790/ —*
2
Dry
X zone: — / —
J zone: — / —
X zone: 790/ —
J zone: 790/ —
*1: Fan mode only
*2: Cooling mode only
3-1. Indoor fan control - (04-49) - 3. Fan control
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
