¢ Models: ASHG18KMTB, ASHG22KMTB, and ASHG24KMTB
Unit: mm
980 240
280
Outline of indoor unit
for pipe inlet Ø65for pipe inlet Ø65
37
37
400 9041377
7341761 429
115
72
2-5. Wall mounted type - (01-37) - 2. Dimensions
