Fujitsu AUXG12KVLA Design & Technical Manual

Power supply
(50 Hz, 230 V)
Indoor rated
Wiring spec. of connection
cable
(Indoor unit to outdoor
unit)
Type Model name
MCA
Input
power
FLA
Cross-
sectional
area
Limited
wiring
length
(A) (W) (A)
(mm
2
)
(m)
Wall mounted
ASYG07KGTB 0.25 23 0.20
1.5 26
ASYG09KGTB 0.30 27 0.24
ASYG12KGTB 0.30 27 0.24
ASYG14KGTB 0.37 33 0.29
ASYG07KGTE 0.25 23 0.20
ASYG09KGTE 0.30 27 0.24
ASYG12KGTE 0.30 27 0.24
ASYG14KGTE 0.37 33 0.29
ASYG07KGTF 0.25 23 0.20
ASYG09KGTF 0.30 27 0.24
ASYG12KGTF 0.30 27 0.24
ASYG14KGTF 0.37 33 0.29
ASYG18KMTB 0.44 38 0.35
ASYG22KMTB 0.49 47 0.39
ASYG24KMTB 0.55 62 0.44
ASYG18KMTE 0.44 38 0.35
ASYG22KMTE 0.49 47 0.39
ASYG24KMTE 0.55 62 0.44
ASYG07KMTB 0.25 23 0.20
ASYG09KMTB 0.30 27 0.24
ASYG12KMTB 0.30 27 0.24
ASYG14KMTB 0.38 33 0.30
ASYG07KMCC 0.25 23 0.20
ASYG09KMCC 0.30 27 0.24
ASYG12KMCC 0.30 27 0.24
ASYG14KMCC 0.38 33 0.30
ASYG07KMCE 0.25 23 0.20
ASYG09KMCE 0.30 27 0.24
ASYG12KMCE 0.30 27 0.24
ASYG14KMCE 0.38 33 0.30
ASYG07KMCF 0.25 23 0.20
ASYG09KMCF 0.30 27 0.24
ASYG12KMCF 0.30 27 0.24
ASYG14KMCF 0.38 33 0.30
- 181 -
10. Electrical characteristics
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu AUXG12KVLA Specifications

General

Brand	Fujitsu
Model	AUXG12KVLA
Category	Air Conditioner
Language	English
