Item no. Part no. Part name Service part
11 9710624322 Main PCB ♦
12 0600063023 Holder ♦
13 9710019005 Communication PCB ♦
14 9710661013 Power supply PCB ♦
15 9306489045 Terminal 3P ♦
16 9900896003 Terminal 5P ♦
17 9707457049 Reactor assy ♦
3-4. Medium static pressure duct type - (02-23) - 3. Indoor unit parts list
