Brief description of mainbo ard
Brief description o f mainboar
d
Information about boards
Be sure to observe the following for boards with ESD :
• You must always discharge static build up (e.g. by touching a grounded object)
before working with the board.
• The equipment and tools you use must be free of static charge.
• Remove the power plug from the mains supply before inserting or removing
boards.
• Always hold boards by their edges.
• Never touch connector pins or conductors on the board.
An overview of the features is provided in the data sheet.
Special features
Your mainboard is ava ilable in different configuration levels. Depending on the confi guration,
your mainboa rd will be equipped w ith or provide support fo r certain features.
This manual describes the most important properties of this mainboard.
Additional information on mainboards is provided in the manual "Basic informat ion on mainboard"
on the "User Documentation" or "O EM Mainboard" CD, or on the Internet.
Interfaces and connectors
The location of the interf
aces a nd connectors of your mainboard is specified
at the beginning of the man
ual.
The com ponents and connect
ors marked are not necessarily present on the mainboard.
External ports
The location of the extern
al connections of your mainboard is speci fie d at the beginning of the manual.
PS/2 keyboard port, violet (optional) PS/2 mouse port, green (optional)
LAN port (RJ-45) Microphone jack (mono), pink
Audio input (Line in), light blue USB – Universal Serial Bus, black
Audio output (Line ou t),
light green
VGA, blue
Serial interface, turqu
oise
The external USB ports on the back of the co mputer support a
combined maximum load of 2 A.
A26361-D2840-Z210-1-8 N19, edition 1 English - 1
