Fujitsu D2840 User Manual

Mainboard D2840/D2841 - Internal co
nnectors and slots
External connectors rear
USB dual channel
1
2
1 = VCC AUX
2 = VCC AUX
3 = Data negative Port X
4 = Data negative Port Y
6 = Data positive Port Y
Data positive Port X
7 =
5 =
GND
8 = GND
9 = Key
10 = Not connected
A26361-D2840-Z240-1-8N19
Front panel
1) 2pin or 3pin connector possible
1
2
HD-LED
Power On/Off
Recovery
Reset
Power On
LED
1)
Recovery inserted = The system allows a
BIOS recovery
Memory Channel B Memory Channel A
Battery
Audio
CPU
LGA775
ICH7
PCI2
PCI1
LAN
TPM
F
AN2
Power Supply 1
Frontpanel
iG41
Super I/O
Parallel Port
Floppy
SAT
A
Audio
Buzzer
USB USB
Audio
Frontpanel
SPDIF
FAN1
PWR 2
PCIex16
PCIex1
IntrusionIntrusion
PSU FanPSU Fan
USB /
LAN
USB
VGA
COM
MSE /
KBD
42
31
A26361-D2840-Z210-1-8 N19, ed ition 1
