Pin No. Description Details

1 SIN/SI Connected to the SIN of

the Microcontroller. Refer

table-2 shown below.

2 NC

3 MD0 Connected to the MD0 pin

of the MCU

4 GND Ground of the Target board

and MCU

5 MD2 Connected to the MD2 pin

of the MCU

6 SOT/SO Connected to the SOT of

the Microcontroller. Refer

table-2 shown below.

7 Pxx P00 of the MCU

8 Pyy P01 of the MCU

9 +Vcc Supply to the MCU

10 NC -

Table 1: Pin Description of Header on the Target Board
